Biotherm BiothermBiomass Boiler Heat Transfer Fluids

A range of high temperature rated heat transfer fluids with antifreeze function, for use in commercial and domestic biomass heating systems

To prevent internal corrosion, scaling and biological fouling all Biotherm products are formulated with long-life inhibitors which exceed ASTM D1384 standards.

Launched in 2010 Biotherm DTX represents a major step forward in heat transfer and pumping efficiency, providing >10% increase in heat recovery when compared with Propylene Glycol based fluids.

Biotherm Range

BioTherm DTX BioTherm DTX

A ABAaa

High Efficiency Non Toxic Heat Transfer Fluid with Antifreeze. Based on Ethylene Glycol blended with patented DeTox™ additive and ASTM D1384 High Temperature Rated Inhibitors for use in Biomass Heating Systems.

Show more...

  • Summary - Rating: ASuitable for biomass boiler heating systems and other heating applications where a non-toxic classification is preferred. High efficiency and more cost effective than MPG and bio-based coolants.

  • Efficiency - Rating: BHigh thermal conductivity and low viscosity at sub-zero temperatures, results in increased heat transfer efficiency and increased heat recovery.

  • Antifreeze - Rating: AProvides protection down to -50°C and less volume is required to achieve the same freeze-point protection, when compared with MPG based fluids.

  • Corrosion Control - Rating: aLong-Life high temperature rated formulation with synergistic corrosion inhibitors to exceed ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: aClassified as Non-Toxic and Food-Safe. Suitable for systems where low-toxicity is stipulated or preferred.

  • Density:1.11 g/cm³

  • pH:8.0 - 8.5

  • Boiling Point:>100°C

  • Characteristics:a clear, straw coloured, slightly viscous liquid. It is mildly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of BioTherm DTX %

Refractive Index

-10

22.0

1.356

-15

28.0

1.362

-20

33.0

1.367

-25

38.0

1.372

-30

42.0

1.376

-35

46.0

1.380

Request

Show less

BioTherm BE2 BioTherm BE2

B BBAAD

Industrial Heat Transfer Fluid with Antifreeze. Based on Ethylene Glycol and ASTM D1384 High Temperature Rated Inhibitors for Biomass Heating Systems.

Show more...

  • Summary - Rating: BSuitable for biomass boiler heating systems and other heating applications where a toxic classification is not an issue. High efficiency and more cost effective than Biotherm BP8 and VB4

  • Efficiency - Rating: BHigh thermal conductivity and low viscosity at sub-zero temperatures, results in increased heat transfer efficiency and increased heat recovery.

  • Antifreeze - Rating: AProvides protection down to -50°C and less volume is required to achieve the same freeze-point protection, when compared with Biotherm BP8 and VB4.

  • Corrosion Control - Rating: ALong-Life high temperature rated formulation with synergistic corrosion inhibitors to exceed ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: DClassified as Harmful but usually considered as Toxic. Suitable for industrial cooling systems where toxicity is not an issue.

  • Density:1.07 g/cm³

  • pH:8.5

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is mildly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of BioTherm BE2 %

Refractive Index

-10

25.0

1.349

-15

27.0

1.355

-20

32.0

1.359

-25

37.0

1.363

-30

41.0

1.366

-35

45.0

1.369

Request

Show less

BioTherm BP8 BioTherm BP8

B BCBAA

Non Toxic Heat Transfer Fluid with Antifreeze Function. Based on Propylene Glycol and ASTM D1384 High Temperature Corrosion Inhibitors for Biomass Heating Systems.

Show more...

  • Summary - Rating: BSuitable for biomass boiler heating systems where low toxicity is preferred. Average efficiency but higher cost compared with Biotherm VB4 fluid.

  • Efficiency - Rating: CAverage thermal conductivity and higher viscosity at sub-zero temperatures, results in reduced heat transfer efficiency and increased energy demands, compared with Biotherm DTX. Good Specific Heat capacity helps improve overall performance.

  • Antifreeze - Rating: BProvides protection down to -50°C but greater concentration (% volume) is required to achieve the same freeze-point protection, compared with Biotherm DTX and BE2.

  • Corrosion Control - Rating: ALong-Life high temperature rated formulation with synergistic corrosion inhibitors to exceed ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for systems where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.15 g/cm³ depending on inhibitors

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is mildly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of BioTherm BP8 %

Refractive Index

-10

25.0

1.356

-15

33.0

1.364

-20

39.0

1.370

-25

44.0

1.373

-30

48.5

1.380

-35

52.5

1.383

Request

Show less

BioTherm VB4 BioTherm VB4

B BCBAA

Ecologically and Environmentally Friendly Non Toxic Heat Transfer Fluid with Antifreeze. Based on Refined Vegetable Extracts and ASTM D1384 proven Corrosion, Scale and Biological Inhibitors, for use in Biomass Heating Systems.

Show more...

  • Summary - Rating: BSuitable for biomass boiler heating systems where low environmental impact and ecological sustainability is preferred. Average efficiency but lower in cost compared with MPG based fluids.

  • Efficiency - Rating: CAverage thermal conductivity and high viscosity at sub-zero temperatures, results in lower heat transfer efficiency and increased energy demands when compared with Biotherm DTX and BE2.

  • Antifreeze - Rating: BProvides protection down to -50°C but more volume is required to achieve the same freeze-point protection compared with Biotherm DTX and BE2.

  • Corrosion Control - Rating: ALong-Life high temperature rated formulation with synergistic corrosion inhibitors to exceed ASTM D1384 standards. Also contains broad-spectrum biological inhibitors and polyacrylates to prevent scale precipitation.

  • Toxicity - Rating: AClassified as Non-Toxic and Food-Safe. Suitable for systems where low-toxicity is stipulated. LD50 Oral Rat >20,000mg/kg body weight.

  • Density:1.02 - 1.26 g/cm³

  • pH:7.5 - 9.0 depending on inhibitors

  • Boiling Point:>100°C

  • Characteristics:a clear, slightly viscous liquid. It is slightly sweet to the taste and has a non-pungent but characteristic aroma.

  • Available in: 5, 10, 15, 20, 25, 205 & 1000 litre containers and bulk tankers.

Frost Protection °C

v/v of BioTherm VB4 %

Refractive Index

-10

25.0

1.355

-15

32.0

1.362

-20

38.0

1.367

-25

43.0

1.372

-30

48.0

1.377

-35

52.0

1.380

Request

Show less
